SKU : 2B0604
Product Code: 2B0604
Design: Bore with Keyway
Grooves: Double
Belt Section: B (21/32” 17mm)
Pitch Circle Diameter: PCD: 6" (152.4mm)
Bore Size: 1" (25.4mm)
Keyway Dimensions:
Height = 1/8" (3.17mm)
Width = 1/4" (6.35mm)
When purchasing a pulley for your engine, there are four measurements to consider. Please check the listing picture for reference.
Pitch Circle Diameter (PCD)
Belt Section Type
Bore dimension
Keyway dimension
Jono & Johno offers a 12-month warranty on most products.
We pride ourselves on selling good quality gear and will be fair and prompt in honouring our warranties. If you’re in trouble, we’ll help you out.
The exact warranty coverage depends on two factors:
Minor faults caused by the user
Minor faults caused by the manufacturer
Major faults caused by the manufacturer
Major faults caused by the user
If you need to return your product:
Some products are not covered by warranty, including:
If your product is out of warranty and has failed despite minimal use, contact us. We may assess it on a case-by-case basis. If a manufacturer defect is identified, we aim to be fair in resolving the issue—but this is at our discretion.
SKU | 2B0604 | |
Model # | 2B0604 | |
Barcode # | 682157269419 | |
Brand | Unbranded | |
Shipping Weight | 1.6500kg | |
Shipping Width | 0.050m | |
Shipping Height | 0.050m | |
Shipping Length | 0.050m | |
Shipping Cubic | 0.000125000m3 | |
Unit Of Measure | ea |
